$290,000.00+ GST

IMPACT CRUSHER | TRACKED | 6127 HOURS

Recent trade-in machine,  just out of work site.  Ready to go to WORK condition, low year model 2018.

This unit is in excellent shape, PERFECT for those looking to get into recycled aggregate processing operation / sand & gravel production.  A very versatile and productive crusher.

Location : ex Christchurch

DESCRIPTION

The Finlay® I-100RS is a direct drive horizontal impact crusher with variable speed.  The machine features a 2.44m x 1.2m (8’ x 4’) single deck screen for sizing and recirculating oversize material back to the crushing chamber. The sizing screen can be quickly detached for applications that do not require resizing or recirculation of materials for further processing. The I-100RS features hydraulic folding of all conveyors.

FEATURES

• Direct drive Ø860mm x 860mm (Ø34” x 34”) crusher chamber with belt tensioner system.
• Hydraulic apron setting assist provides adjustment of the aprons and hydraulic overload protection in event that an un-crushable object enters chamber.
• Detachable single deck screen returns oversize material back to the crusher via the onboard recirc system.
• Detachable screen, fines, and transfer conveyor for open circuit crushing.

SPECS

• Rotor diameter: Ø860mm (34”).
• Crusher – Inlet opening: 860mm x 610mm (34” x 24”).
• Crusher – Drive arrangement: Direct drive via clutch.
• Recirc conveyor hydraulically folds for transport.
• Screen box: Top deck: 2.44m x 1.2m (8’ x 4’).
• Main conveyor: 900mm (36”).
• By-pass conveyor: 500mm (20”).
• CAT C7.1 engine.
• Weight: 33,250Kg.

$290,000 + GST ex Christchurch

$333,500 incl. GST

Machine is outside manufacturers warranty period so is sold with no warranty.

We offer competitive transport options across NZ.
