WALKER RX48

POA

RX48 – $19,995 Inc. GST (48” SD Deck )

NON-COLLECTION TRACTOR – Side Discharge Mower

Increased productivity and operator comfort are found in the RX through of a variety of improvements. Higher ground speed is achieved by using 20″ drive tires, and a smoother ride is the result of the combination of a split tail wheel design and a comfort seat, which is standard on the RX.

Features like the Kohler KT722, Hydro-Gear ZT3100 transaxles, and updated deck arms for using existing Model R decks, contribute to the overall performance of the RX.

COMFORT

Walker Comfort Seat and 2000 lumen LED headlights help maintain productivity during days that start early and end late.

PERFORMANCE

With commercial-grade Hydro-Gear® ZT3100 transaxles, the Rx maintains the agile steering and handling that Walker operators have come to expect.
These transaxles, matched with 20-inch drive tires increase ground speed to 8 MPH which means exceptional productivity.
The Kohler KT722 engine uses a PRO performance package to increase air, oil and fuel filter capacity for extra protection along with Smart-Choke™ technology, so no choke is needed.

KEY FEATURES

LED headlight kit for mowing in the dark
Commercial warranty
Commercial duty – Full welded tilt-up deck
Comfort seat
Spread axle tail wheels for exceptional stability
KOHLER KT722 engine 22 HP displacement, increased horsepower and greater torque
ZT3100 Hydro-Gear® commercial-grade transaxles
20-inch drive tires for superior traction on diverse terrains

WALKER RX48

UDC Finance available - Find out more

SPECIFICATIONS & DOWNLOADS

Deck	48" Side Discharge (Belt Drive)
Deck Suspension	Independent Torsion-Flex Frame with Caster Wheels and Counterweight Springs
Mulching Kit	1163P – Mulch Kit – for DS48-R 48” Deck – Quick Change (Mach II blade and baffle) 48" deck
Type	Non-Collection
Power	22 HP
Engine	Kohler KT722 Displacement : 747cc Max Power: 22HP @ 3600 RPM
Ideal Application	Residential / Commercial Properties
Key Attributes	Agile, Accessible, Compact
Cooling System	Air
Fuel	Unleaded – min 87 octane
Ground Speed	Commercial ground speed @ 12.9 Km/h with 20" drive tires
Headlights	LED Headlight kit for mowing in dark
Transaxles	Commercial Hydro-Gear ZT3100 transaxles
Deck Height Adjuster Kit	48” Part No. 1900R
Elec. Deck Lift	Elec. Deck Lift – 48" Decks – C/w spring mounts Part No. 1870WRW
Height	Tractor Only : 42.25 in / (107 cm). Tractor w/ 48” deck: 42.25 in (107 cm).
Length	Tractor Only: 62 in (159 cm). Tractor w/ 48” deck: 92.25 in (234 cm).
Weight	218.6 KG (Excluding deck) Tractor w/ 48” deck : 308 kg (Tractor with deck)
Width	Tractor Only : 40 in (102 cm). Tractor w/ 48” deck: 49 in (124 cm).
