Home / Mining, Quarry & Aggregates / Pugmills / RAPIDMIX 400C Mobile Pugmill
RAPIDMIX 400C Mobile Pugmill
RAPIDMIX 400C Mobile Pugmill
RAPIDMIX 400C Mobile Pugmill
RAPIDMIX 400C Mobile Pugmill
RAPIDMIX 400C Mobile Pugmill
RAPIDMIX 400C Mobile Pugmill
RAPIDMIX 400C Mobile Pugmill
RAPIDMIX 400C Mobile Pugmill

RAPIDMIX 400C Mobile Pugmill

POA

The Rapidmix 400C Volumetric Mobile Pugmill Plants are self-contained with onboard genset power. They are capable of transitioning from travel mode to fully operational within a few hours. Suitable for any mixing application where a binder needs to be mixed into a base material.

FEATURES & BENEFITS

  • Aggregate hopper with variable speed belt feeder.
  • Onboard cement/binder silo.
  • Onboard water system.
  • Twin-shaft continuous mixer.
  • Outloading conveyor to transport material from the mixing chamber to the truck.
  • Pneumatic system for gob hopper doors and silo filter.
  • Hydraulic power pack for levelling plant, erecting silo and operating out loading conveyor.
  • Control panel for manual or automated operation.

The Rapidmix 400C plants feature volumetric measurement mixing technology. This means materials flow continuously and are measured by volume using a calibrated rotary valve, calibrated fixed gate opening, or a combination of the two. A predetermined volume of each ingredient is obtained in a designated time interval. This requires the proper relationship among ingredients to be maintained through calibration of speed and volume for a smooth, continuous release of material.

Producing up to 400 tonnes of material per hour, Rapidmix 400C plants deliver the most accurate, reliable, and powerful mobile continuous mixing technology available. Concrete, construction, and environmental contractors around the world rely on Rapidmix to meet their soil cement, soil stabilization, and roller compacted concrete production needs.

RAPIDMIX 400C Mobile Pugmill

UDC Finance available - Find out more

Categories: Pugmills, Mixing Plant
Get a Quote

Specifications & Downloads

Download Product Brochure
  • Additional information

SPECIFICATIONS & DOWNLOADS

Plant Length in Travel Mode

19.48m

Plant Length When Erected

21.51m

Plant Width

3m

Plant Height in Travel Mode

4.09m

Plant Height When Erected

13.72m

Plant Weight

33,420kg

Aggregate Hopper Capacity

11.93m³

Mixer

110rpm Twin-Shaft Mixer with 72 Ni-Hard Cast Paddles

Cement/Binder Silo

43.5 Tonne Capacity

Conveyor

800mm 3-Ply Belt Outloading Conveyor
1.15m³ Capacity Gob Hopper

Onboard Water System

1749 Litre Water Tank
Pumps
Spray Bars
Flowmeter
