Up to 290 Tonnes Per Hour. | Wear-Resistant Feed Hopper. Capacity: 3.3m³ Length: 3.8m Width: 2m | Vibrating Grizzly Feeder. Length: 3.8m Screen Size: 1500mm x 950mm | Feed Opening: 1030mm x 790mm Rotor Speeds: 630 – 800rpm Min. CSS: 20mm (Lower Apron) Min. CSS: 50mm (Upper Apron) Hydraulic Overload Protection. | Width: 1000mm Discharge Height: 3.42m | 34,200kg | Width: 5.22m Length: 14.66m Height: 4.12m | Width: 2.9m Length: 14.76m Height: 3.18m | Blasted Rock River Rock C & D Waste Foundry Waste Processed Ores Processed Minerals |
HireKey Features and Benefits:
The Powerscreen Trakpactor 290 & 290SR Impact Crusher performs in the most challenging of applications, such as construction and demolition, asphalt, concrete, and natural rock. The compact design allows it to operate in small landing spaces and easily be transported from site to site. The integrated system ensures the required product specification is achieved with oversize material either being recirculated back to the crusher or stockpiled.
SPECS:
We offer competitive transport options across NZ.
CONTACT US
Phone
021 278 0738 – Lionel Stanners (North Island)
021 278 7456 – Daniel Bartley (South Island)
0508 STEVENS
Email
sales@stevensgroup.co.nz
Specifications:
| Output Potential | Up to 290 Tonnes Per Hour. |
|---|---|
| Hopper | Wear-Resistant Feed Hopper. |
| Feeder | Vibrating Grizzly Feeder. |
| Crusher | Feed Opening: 1030mm x 790mm |
| Product Conveyor | Width: 1000mm |
| Weight | 34,200kg |
| Working Dimensions | Width: 5.22m |
| Transport Dimensions | Width: 2.9m |
| Applications | Blasted Rock |
